| Moisture: | |
|---|---|
| Voltage: | |
| Capacity: | |
| Quantity: | |
500kg/hr PE PP Film Bag Crushing Washing Recycling Squeezing Dry Machine/Line/Plant
Usage/Function:
Our Film washing and recycling machine could deal with waste plastic such as plastic bags, agriculture film, woven bags, plastic package products etc. The whole production line is surely of standard and high quality with CE certification and ISO 9001.
Specification:
Name | (KW) Motor power
| (mm) dimension
| (T/H) Water consumption
| (mm) Stainless steel standard
| Electric standard
|
Belt conveyer | 2.2KW
| 4500*900*2700 | - | - | According to customer’s standard
|
Crusher | 55KW
| 2200*2200*3000 | 0.6-1.0 | - | |
Screw conveyer | 3KW
| 4100*900*2500 | - | 3-5 | |
Film floating washer | 2.2KW*2
| 6500*2500*2300 | 3-4 | 3-5 | |
Screw conveyer | 2.2KW
| 3400*500*2600 | - | 3-5 | |
High speed friction washer | 30KW | 3500*1800*2000 | 1-2 | 3-5 | |
Screw conveyer | 2.2KW | 3400*500*2600 | - | 3-5 | |
Film dewatering machine | 75KW
| 2200*2200*2000 | - | 5 | |
Drying system1 | 7.5KW
| 3600*2300*1900 | - | 3-5 | |
Storage hopper for transition | - | 3700*1700*4200 | - | - | |
drying system 2 | 7.5KW | 3600*2300*1900 | - | - | |
storage hopper | 2.2KW*2 | 3800*1700*4200 | - | - | |
Electrics | - | 2000*450*1780
| - | - |
PE PP Film Bag Crushing Washing Recycling Squeezing Dry Machine/Line/Plant Models:
Model | Power | Water Consumption | Capacity |
RFW300 | 80kw/h | 4-6 ton/h | 300kg/h |
RFW500 | 150kw/h | 6-8 ton/h | 500kg/h |
RFW1000 | 225kw/h | 8-10 ton/h | 1000kg/h |
500kg/hr PE PP Film Bag Crushing Washing Recycling Squeezing Dry Machine/Line/Plant FEATURES:
1) Latest structure of crusher, ensure maximum to get 3000kg/h for LDPE film.
2) High efficient label/paper removing system can completely separate paper tag and plastic film.
3) Multiple-Channels washing tank design,best washing effect.
4) Squeezer application on drying, ensure moisture 3%.
5) High output,2000kg/h-3000kg/h.
Why Retech?
We focused on plastic recycling machines with more than 12 years.
Retech accept customzied PP PE film recycling solutions according to customer's requirements.
We provide turn-key project solution.
All parts contact with material are SUS stainless steel 304,thickness more than 3mm.
Fast reaction to customers concerns,24 hours online service.
