500kg/h Plastic PE LDPE HDPE BOPP LLDPE Film Compactor Double Stage Die Face Cutting Pelletizing Line
Product Description:
"RCDJ" Series PP PE Film Double Stage Die Face Cutting Pelletizing Machine is working to process the soft plastics such as different kinds of soft plastic PE/LDPE/LLDPE/HDPE/BOPP films,PP woven non-woven/fabric/raffia/nets, PS/EPS/XPS foam,etc.
Models:
Model | Screw Diameter | L/D | PE(Output) | PP(Output) |
RCDJ85/100 | 85mm/100mm | 33:1 | 160-220kg/h | 120-200kg/h |
RCDJ100/120 | 100mm/120mm | 33:1 | 260-380kg/h | 220-300kg/h |
RCDJ130/150 | 130mm/150mm | 33:1 | 450-550kg/h | 380-500kg/h |
RCDJ160/180 | 160mm/180mm | 30:1 | 650-800kg/h | 500-600kg/h |
RCDJ180/200 | 180mm/200mm | 28:1 | 800-1000kg/h | 600-800kg/h |
Main Units on PP PE film recycling machine:
1. Belt conveyor with metal detector
The belt conveyor is to sending the plastic flakes into compactor machine. The belt is made of PVC in 4mm thickness. On top of belt,we usually design a metal detector to alarm before sending it into compactor,it is to protect the blades and screw/barrel.
The belt conveyor is with current linkage set with compactor, if the compactor is overload,the belt stops, while the current is normal,the belt keep working.
2. Compactor/Agglomerator
Compactor machine is working with crushing and compact functions,with moving/fixed blades inside of compactor, the material will get fully stir and friction immedietely. Moving baldes friction creat heat to dry materials and make it compact. It is easy to feeding. You can also easily to inspect the inside working of compactor by side inspection window.
Film with moisture,our new wet degassing dusting collection system is a big improvement for film with humidity.
The optimum screw design(turn to the material to be processed) enables the reverse degassing to be true in the cutter compactor,it is a help of degassing zone of extruder.
3. Extruder/Filtration
The main extruder is designed with a vacuum system,if your material sometimes is a little wet or with some useless elements. The vacuum degassing can absord the impurities to improve the ending quality of granules.
In the end part of the extruder,we put a pressure sensor to reminding operator to change the net timely.
4. Die face cutting system
Here is for die face cutting system, the granules will cutted and fall into water in short time. The thickness of granules is depend on the speed of motor(Inverter control)
RCDJ Series PP PE film granulating line can be processing below plastic materials:
(1) HDPE,LDPE,LLDPE,PP such as films,bags,flakes,film rollers,stretch film,shrink film,packing film,multi-layer film,T-shirt bag cut-offs pelletizing machine
(2) Foamed PE,EPS,EPE,XPS: rolls,bags,sheet,food container,fruit net,cover pelletizer
(3) Textile:PP fiber,raffia,silk,yarn,woven bags,non-woven fabric,jumbo bag granulating line
(4) Plastic Granulating Line for PP raffia/woven sack/BOPP film/CPP film recycling,PE+PA laminated film.
(5) Meanwhile,it can be pelletizing both soft film and rigid flakes in one machine.The point is add a controlling valve in the feeding part.
ABOUT RETECH:
RETECH is a manufacturer of PLASTIC GRANULATOR MACHINE and PLASTIC WASHING LINE with strong R&D of technical force.
With a simple operation, good quality, reasonable prices and experienced designs, our plastic recycling machine are extensively used in the field of waste plastic recycling.
15+ years experience in plastic recycling machinery. we focus on produce the plastic recycling machine and plastic pelletizing line and plastic washing line.Such as plastic bottle recycling machine,PP raffia recycling machine,plastic film recycling machine,chemical fiber/nylon fiber pelletizing machine,PP PE film granulator plastic recycling machine plant,PET bottle flakes pelletizing line,Crusher,Shredder,Agglomerator and so on.
We are waiting for your further concerns.
