Heavy Printed Coated Metailized PE CPP CPE BOPP Film Recycling Pelletizing Line
Description of granulator:
Our BOPP metalized film pelletizing line can drain away moisture and exhaust gas during the recycling production process, so that while the discharge is stable, the rubber particles produced are stronger. It is derived from the special screw design of the granulator after hardening treatment and the high-torque gearbox design. The BOPP metalized film recycling pelletizing machine is smooth and noiseless during operation.
Such a granulator has good mixing performance, high output, and at the same time guarantees the excellent quality of the product.
Features:
1) Single stage extruder and double stage extruders can be used according to user’s requirement or material condition.
2) Plastic pelletized PP,BOPP, HDPE, ABS and other engineering plastics or general plastics recycling and granulation.
3) Granules cutting type: water ring face cutting, strip/noodle type cutting and hot cutting.
4) Waste woven bags and waste film can be directly put into the granulation line without crushing.
5) The main engine is equipped with full automatic control cabinet and PLC operating system.Our new BOPP film pelletizing machine is easy to operate and has stable performance.
6) Low energy consumption, remarkable energy saving effect, high output, mechatronics.
Single Stage BOPP Film Pelletizing Line:
Model | Data of compactor | Data of single screw extruder | Throughput rate(Kg/hr) | |||
Efficiency volume (Liter) | Motor power (KW) | Diameter of screw(mm) | L/D | Motor power(KW) | ||
RCDJ85 | 300 | 37 | 85 | 33 | 55 | 160-220 |
RCDJ100 | 500 | 55 | 100 | 33 | 90 | 280-360 |
RCDJ130 | 800 | 75 | 130 | 33 | 132 | 450-550 |
RCDJ160 | 1000 | 110 | 160 | 30 | 185 | 650-750 |
RCDJ180 | 1200 | 132 | 180 | 28 | 250 | 800-1000 |
Model | Data of compactor | Data of single screw extruder | Throughput rate(Kg/hr) | |||
Efficiency volume (Liter) | Motor power (KW) | Diameter of screw(mm) | L/D | Motor power(KW) | ||
RCSJ85 | 300 | 37 | 85-100 | 33 | 55 | 160-220 |
RCSJ100 | 500 | 55 | 100-120 | 33 | 90 | 280-360 |
RCSJ130 | 800 | 75 | 130-150 | 33 | 132 | 450-550 |
RCSJ160 | 1000 | 110 | 160-180 | 30 | 185 | 650-750 |
RCSJ180 | 1200 | 132 | 180-200 | 28 | 250 | 800-1000 |
No. | Name | Quantity |
1 | Belt conveyor with metal detector | 1 |
2 | Compactor | 1 |
3 | RCSJ130/33 main extruder | 1 |
4 | RCSJ150/12 main extruder | 1 |
5 | Hydrualic screen exchanger | 2 |
6 | Die face cutting system | 1 |
7 | Water flume | 1 |
8 | Dewatering machine | 1 |
9 | Vibrating screen | 1 |
10 | Blower conveying system | 1 |
11 | Storage hopper | 1 |
12 | Electric panel | 1 |
