PET Bottle Washing Line

PET Bottle Washing Line is designed for processing post consumer PET polyethylene bottles like Cola bottle,mineral pure drinking water bottle, pesi cola bottle,etc.
By professional design/manufacture on PET bottle washing machinery, we can supply completely PET bottle washing line from 1000kg/h to 5000kg/h.
Usually, after washing and cleaning, PET flakes will be used on PET pelletizing machine for fiber fabric,PET strap production line,PET sheet,etc.
  • RT series PET Bottle washing machine
  • RETECH
  • 8477201000
Plastic:
Production Capacity:
Availability:
Quantity:

PET Bottle Washing Line

PET Bottle Washing Line

Working Flow:

Belt conveyor → Bale opener machine → Belt conveyor → Pre-washer (trommel) →Belt conveyor → Mechanical label remover → Manual separating table → Metal detector →Belt conveyor → Crusher *2→ Screw conveyor*2 → Floating washer →Screw conveyor → Hot washer chamber *2 →Screw conveyor*2 → High speed friction machine → Screw conveyor → Floating washer → Screw conveyor →Floating washer → Screw conveyor → Horizontal dewatering machine → Drying pipe system → Zig zag air classification system → Storage hopper → Control cabinet


微信图片_20220314104048


Models of PET Bottle Washing Line:

Model

CAPACITY(kg/h)

POWER CONSUMPTION(kw)

WATER CONSUMPTION(ton/h)

MANPOWER

HUMIDITY CONTENT

RS-500

500kg/hour

180kw

3-4ton/h

4

≤1%

RS-1000

1000kg/hour

210kw

6-7ton/h

6

≤1%

RS-2000

2000kg/hour

320kw

8ton/h

6

≤1%

RS-3000

3000kg/hour

405kw

10ton/h

8

≤1%


Final Products (PET Flakes) Quality Reference:

NO.

DESCRIPTION

AA level (ppm)

A level (ppm)

1

PVC   content

≤25

≤100

2

PE/PP   color flake/metal and other impurity content

≤75

≤100

3

Total   impurity

≤100

≤150

微信图片_20220314131826


Advantages Of PET Bottle Recycling Line:

1.Final products has good quality. When process PET bottle, final products humidity below 1%, impurities100ppm,PVC label content 100ppm . The whole line capacity between 300kg/h-2000kg/hour .

2.Parts which contact material use SUS304 stainless steel, thickness more than 3mm, ensure long service lift time .

3.World famous brand components applied on the production line- e.g. Siemens contactor, Omron temperature, FUJI invertor, Siemens PLC controller, etc.

4.The whole production line with CE certification, ISO9001 certification.


Our Service:

· RETECH will provide all the machines for the complete production according to customer's requirements.

· RETECH will provide complete service for factory layout and other information to help customer to build the factory.

· RETECH will provide good service for machine installation and training, until the customers can run the machines and make stably production.

· Except one year quality guarantee, we will provide after-sell service for all the life.

· For long-term cooperation, we always provide good quality, good price and good service to customer.


About us:


RETECH is located in Zhangjiagang city (100 kilometers from Shanghai), The target of RETECH is to offer the best quality plastic recycling machines to the customers from all over the world. With the advanced technology, experienced engineers and skilled workers, we have the capability to manufacture specific machines according to customer's requirements. Our products serviced hundreds of plastic companies over 80 nations and regions worldwide.
Excellent quality and professional service is the promise made by RETECH to new and old friends. We are looking forward to establishing the good cooperation relationship with you on the basis of mutual benefits
