BOPET Film PET Flake Recycling Pelletizing Machine
Technical parameter of extruder:
Power supply | Voltage ：380V, +5%/-5%；, 3 phase；50HZ+-2% Control voltage：24VDC+220VAC |
Water line | To equipment and to pool |
Installation power | ~268KW（actual consumption：70%) |
Water supply | Consumption：2~3T/H（as recommended） Pressure：0.4 Mpa |
Labour work | 2~3 operators |
General information
Raw material | PETG film flakes |
Final product & Output capacity | PETG pellets / 500kg/h |
Machine color | Standard color: Blue or gray |
Description of final product | size: 3-5mm |
Machine List of PET flakes pelletizing machine:
No. | Machine | Qty. |
1 | Belt conveyor | 1 set |
2 | Compact drying system | 1 set |
3 | SJ-110/36 single screw extruder | 1 set |
4 | 2000 piston type hydraulic screen changer system with large filtration area | 1 set |
5 | Water ring vacuum system | 1 set |
6 | Chute | 1 set |
7 | Under water pelletizer | 1 set |
8 | Vertical centrifugal dryer | 1 set |
9 | Dewatering vibration sieve | 1 set |
10 | Blower and silo | 1 set |
11 | Electric Cabinet | 1 set |
